FARO CAM2 MEASURE 10

FARO CAM2 MEASURE 10

FARO CAM2 Measure 10 is an all-in-one metrology software for users that are looking for a single, complete solution for all tactile measurement and non-contact 3D scanning applications. The software is ideal for CAD and non-CAD inspection and Geometric Dimensioning and Tolerancing (GD&T).

CAM2 Measure 10 features image-guided measurement, automatic nominal association to various features, QuickTools and an intuitive user interface. Moreover, the software is delivered with a reliable CAD import tool which increases the ability to load a large amount of CAD data.

Compatible with Faro arms, and Laser trackers Available For Hire or Purchase

OVERVIEW

CAM2 Measure 10 Full:

A comprehensive version ideally-suited for all contact and non-contact 3D measurement applications when point cloud data may be required.

CAM2 Measure 10 Probing:

A limited version ideally-suited for all contact measurement applications when point cloud data is not required.

FEATURES

Import/Export

• Import/export points to a text file

• Import CAD files

•Export measurement results to CAD

•Export Point Cloud to mesh

•Export CAD as XGL

Measurement

•Seamless connection to FARO hardware devices

• Direct measurement mode

• Automatic Projection Plane mode

• QuickTools programming module

• Tube measurement

• Easily align to part

• Live feedback during measurement

• Guided Geometry Measurement

• Repeated part measurement

Programming

• Record steps for a part program (online/offline)

• Play steps in a measurement program

• Integrated programming module

Alignments

• Align my Part Wizard

• Iterative

• 3.2.1

• Six-point surface

• RPS

• Constrained Iterative

Nominals

• Pick features from CAD (single click)

• Create nominal features by entering values

Reporting

• Versatile export formats

• Report with images and in different CS

• Export to HTML, text, Microsoft® Excel, PDF

Live Colour Scan

• Colour scale in the 3D view

• Surface Profile GD&T

• Place labels on your scan to determine deviations at critical locations

• Export scans to text file

SYTEM REQUIREMENTS

Minimum Requirements*

• Processor: Intel Core i5-4200M, Dual Core 2.5GHz

• RAM: 8GB, DDR3

• Hard Drive: 500GB

• GPU: NVIDIA Quadro K1100M

• USB ports: 1 (if using portlock licensing)

• DVD-ROM

Recommended Requirements**

• Processor: Intel Core i7-4600M, Dual Core 2.9GHz

• RAM: 16GB, DDR3

• Hard Drive: 256GB SSD

• GPU: NVIDIA Quadro K3100M

• USB ports: 1 (if using portlock licensing)

• DVD-ROM

High performance Requirements***

• Processor: Intel Core i7-4900MQ, Quad Core 2.80 GHz

• RAM: 32GB, DDR3

• Hard Drive: 512GB SSD + 1TB SATA 6

• GPU: NVIDIA Quadro K5100M

• USB ports: 1 (if using portlock licensing)

• DVD-ROM

* For Point Probe Measurements ** For Point Probe Measurements with Large CAD; Moderate Point Cloud Scanning *** For Heavy Point Cloud Scanning

The following computer operating systems are supported.

• Microsoft® Windows® 7 (32-bit or 64-bit)

• Microsoft® Internet Explorer 7.0

• Adobe® Acrobat® Reader® 6.0 or later (to print manuals)

• Microsoft® Windows® 8 and 8.1 (32-bit or 64-bit)

• Microsoft® Windows® 10 (32-bit or 64-bit)

• Microsoft® Internet Explorer 8.0

• Adobe® Acrobat® Reader® 6.0 or later (to print manuals)

Note: We recommend Windows® 8.1 64-bit Professional operating system for point cloud scanning.
